Key Features

• Compact Design: Lightweight and space-efficient design requiring minimal installation area, perfect for clinics with limited space.
• DICOM Integration: Receives print jobs directly from imaging devices and CS-7 / ImagePilot for seamless workflow integration.
• Fast Throughput: Outputs up to 50 sheets per hour for 14×17 inch film, with first image ready in approximately 105 seconds.
• Precision Output: 87.5 µm pixel size with 12-bit (4094 levels) grayscale gradation ensures diagnostic-quality imaging.
• Multi-Size Support: Compatible with multiple film sizes including 8×10", 10×12", 14×17", and B4 formats for versatile clinical applications.
• Reliable Performance: Uses Konica Minolta TR-S dry medical imaging film with 100-sheet capacity for consistent, high-quality results.

Technical Specifications

• Printing Technology: Thermal head printing at 300 dpi with 84.7 µm pixel resolution for exceptional image clarity.
• Power & Dimensions: AC 100–240V, 50–60Hz power supply. Compact footprint of 530×470×365 mm and weighs approximately 32 kg.
• Film Capacity: Single tray system with 100-sheet capacity, supporting Konica Minolta TR-S dry medical imaging film.

DryPro TH 1 Tray delivers reliable, high-quality thermal imaging in a compact package, making it an ideal solution for medical facilities requiring efficient diagnostic film output with minimal space requirements.
